ATORN cemented carbide indexable insert CNMG 120408-RP2 ACP15T

ATORN cemented carbide indexable insert CNMG 120408-RP2 ACP15T

ATORN cemented carbide indexable insert CNMG 120408-RP2 ACP15T
Item no: 1019403 106

Online price:

Available for immediate delivery

Application
For longitudinal turning and facing with a wide infeed range and stable cutting geometry in favourable cutting conditions

Advantage
  • Very high level of hardness and wear resistance, for high service life requirements with favourable cutting conditions
  • Very robust and stable cutting geometry, optimised for high feed rates in the medium to high infeed range in unfavourable cutting conditions


Brand: ATORN
Shape of indexable insert ISO: C
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 12
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 08
Coating: CVD
Carbide type area ISO: P
Machining conditions for indexable insert: Good
Carbide type ISO: P15
Carbide type: ACP15T
ISO-Code Rotating: CNMG 120408
Material to be processed: Steel | Cast metal
min./max. ap: 0.5-6.0 mm
f min./max.: 0.2-0.5 mm/U
Materials group: P (primary application) | K (secondary application)
f min.: 0,2 mm/r
max. f: 0,5 mm/r
max. ap: 6,0 mm
min. ap: 0,5 mm
Supply type: Roughing - Stable edge at raised feed values
Chip breaker code: RP2
Min./max. Vc in steel: 180-400 m/min
Min./max. Vc in cast iron: 140-520 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 12370051

EAN no.: 4050293564648

Product Datasheet
