ATORN cemented carbide indexable insert CNMG 120408-RP5 HC7610

ATORN cemented carbide indexable insert CNMG 120408-RP5 HC7610

ATORN cemented carbide indexable insert CNMG 120408-RP5 HC7610
Item no: 1018554 120

Online price:

Available in 4-6 working days.

Application
For longitudinal turning and facing with a wide infeed range and stable cutting geometry in favourable cutting conditions

Advantage
  • Very high level of hardness and wear resistance, for high service life requirements with favourable cutting conditions
  • Very robust and stable cutting geometry, optimised for high feed rates in the medium to high infeed range in unfavourable cutting conditions


Brand: ATORN
Shape of indexable insert ISO: C
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 12
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 08
Coating: CVD
Carbide type area ISO: P
Carbide type ISO: P10
Carbide type: HC7610
ISO-Code Rotating: CNMG 120408
min./max. ap: 0.8-6 mm
f min./max.: 0.20-0.40 mm/U
f min.: 0,20 mm/r
max. f: 0,40 mm/r
max. ap: 6 mm
min. ap: 0,8 mm
Supply type: Roughing - Stable edge at raised feed values
Chip breaker code: RP5
Min./max. Vc in steel: 160-320 m/min
Min./max. Vc in cast iron: 160-520 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 10875162

EAN no.: 4050293561777

Product Datasheet
