ATORN indexable insert, positive, VCMT 110304-MP HC7520

ATORN indexable insert, positive, VCMT 110304-MP HC7520

ATORN indexable insert, positive, VCMT 110304-MP HC7520
Item no: 1018615 510

Online price:

Only while stocks last
Replacement article

Application
For longitudinal turning and copy turning with a wide infeed range in moderate cutting conditions

Execution
Sintered cemented carbide indexable insert

Advantage
  • Perfect combination of wear resistance and durability, for high process stability and broad range of applications
  • Positive soft-cutting chip geometry with a wide infeed range and stable blades


Brand: ATORN
Shape of indexable insert ISO: V
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: T
Size of indexable insert ISO: 11
Thickness of indexable insert ISO: 03
Corner radius of indexable insert ISO: 04
Coating: CVD
Carbide type area ISO: M
Machining conditions for indexable insert: Medium
Carbide type ISO: M20
Carbide type: HC7520
ISO-Code Rotating: VCMT 110304
Material to be processed: Stainless steel | Special alloy
min./max. ap: 0.4-2.5 mm
f min./max.: 0.12-0.3 mm/U
Materials group: M (primary application) | S (secondary application)
f min.: 0,12 mm/r
max. f: 0,3 mm/r
max. ap: 2,5 mm
min. ap: 0,4 mm
Supply type: Medium processing - Universal geometry with wide service range
Chip breaker code: MPX
Min./max. Vc in stainless steel: 80-240 m/min
Min./max. Vc in special alloys: 30-60 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 10870461

EAN no.: 4050293081121

Product Datasheet
