Long twist drill bit DIN 341 type N HSS ground MK2 18 mm

Versions

Item no: 1010610 159

Online price:

Catalogue price: You save:

Available in 6-8 working days.

Min. order quantity: 1

Application
For drilling through boring bushings and for drilling deep holes. For drilling steel and cast steel (alloyed and unalloyed), cast iron, malleable iron, spheroidal graphite iron, sinter iron, nickel silver and graphite up to approx. 900 N/mm² strength.

Execution

With Morse taper and flat tangs
Right-cutting
Tip angle 118°
Cone polished section
Steam treated
HSS, ground

Brand: HARTNER
Material to be processed: Steel
Cutting edge diameter: 18 mm
Length: 263 mm
Chip flute length: 165 mm
Angle of the tip: 118 Degree
Cutting material: HSS
Surface: Vaporised
Morse taper size: MK 2
Type: N
DIN: 341
f steel 700: 0,25 mm/r
Coolant supply: 0 - not applicable
Number of cutting edges: 1 PCS
Max. f in cast iron: 0,20 mm/r
Max. f in steel: 0,25 mm/r
Min. f in cast iron: 0,20 mm/r
Min. f in steel: 0,25 mm/r
Shank style: Morse taper

Manufacturer part no.: 82210 18

EAN no.: 4031096044223

Product Datasheet Datasheet cutting values
