ATORN indexable insert screw-in milling cutter 90° diameter 16.0mm T=4

ATORN indexable insert screw-in milling cutter 90° diameter 16.0mm T=4

ATORN indexable insert screw-in milling cutter 90° diameter 16.0mm T=4
Item no: 1017500 122

Online price:

Available in 5-7 working days.

Application
For universal use in all materials.

Execution
  • With screw-in thread
  • Wear-resistant, nickel-plated version
  • With internal cooling
  • Clamping screw tightening torque (indexable insert) M1.8 = 0.7 Nm


Brand: ATORN
Cutting edge diameter (D): 16 mm
Clearance length (L3): 21 mm
Length (L1): 21 mm
Thread dimension (d): M8
max. ap: 5,2 mm
Number of cutting edges: 4 PCS

ATORN-No.: 12230327

EAN no.: 4050293433906

Product Datasheet
