ATORN surface chuck (Weldon) SK40 diameter 40 mm A=90 mm

ATORN surface chuck (Weldon) SK40 diameter 40 mm A=90 mm

ATORN surface chuck (Weldon) SK40 diameter 40 mm A=90 mm
Item no: 1021630 510

Online price:

Available in 8-10 working days.

Application
For clamping tools with straight shank and clamping surface in accordance with DIN 1835 B.

Execution
  • Alloyed case-hardening steel, core tensile strength at least 950 N/mm²
  • Case-hardened HRc 60 ± 2 (HV 700 ± 50), hardness depth 0.8 mm ± 0.2 mm
  • Taper angle tolerance quality < AT3 in accordance with DIN 7187 and DIN 2080
  • Max. concentricity < 0.005 mm
  • With ring groove and plastic edge protection ring on the pull stud
  • Functional surfaces precision-ground, all other surfaces black-oxide
  • With Balluff chip hole

Advantage
Precision cross-hatch pattern on the contact surface for maximum accuracy

Delivery
1x SK40 or SK50 surface chuck (Weldon) (DIN2080)

Notes
The previous standard DIN 69871-1 was superseded by ISO 7388-1.

Brand: ATORN
Tool holding device: SK 40
Clamping diameter (d): 40 mm
Projecting length (A): 90 mm
Outer diameter (D): 80 mm
Balancing quality: G 2.5 at 25,000 rpm

ATORN-No.: 22661303

EAN no.: 4050293714562

Product Datasheet
Versions
