Shrink-fit chuck DIN 69893 shape E HSK40 extra-long diameter 3 x 120 mm

Shrink-fit chuck DIN 69893 shape E HSK40 extra-long diameter 3 x 120 mm

Shrink-fit chuck DIN 69893 shape E HSK40 extra-long diameter 3 x 120 mm
Item no: 1021599 120

Online price:

Available in 6-8 working days.

Application
For clamping carbide, HSS and steel shanks with a tolerance of h6.

Execution
  • Highest level of concentricity and taper tolerance
  • Manufactured in air-conditioned production

Advantage
  • High retention forces and long service life thanks to the use of high-quality heat-resistant steels and special heat treatment processes
  • Patented taper allows automatic shrink processes and simplified handling

Notes
For shrinking equipment, see art. no. 1021588-1021595.

Brand: DIEBOLD
Tool holding device: HSK 40
Clamping diameter (d): 3,0 mm
Projecting length (A): 120,0 mm
Outer diameter (d3): 20,0 mm
Tapered diameter (d2): 15,0 mm
Clamp in depth (l2): 20,0 mm
Max. adjustment travel (max. V): 5 mm
Coolant supply: Internal
Balancing quality: G 2.5 at 40,000 rpm
Construction length: Long
Max. concentricity: 0,003 mm
Thread dimension: M6

Manufacturer part no.: 72.568.500.015

Product Datasheet
