ATORN carbide indexable insert VCMT 160404-FP1 ACP15T

ATORN carbide indexable insert VCMT 160404-FP1 ACP15T

ATORN carbide indexable insert VCMT 160404-FP1 ACP15T
Item no: 1019425 103

Online price:

Available in 6-8 working days.

Advantage
  • Long service life
  • Optimised chip breaker for excellent chip control
  • Smooth chip flow


Brand: ATORN
Shape of indexable insert ISO: V
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: T
Size of indexable insert ISO: 16
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 04
Coating: PVC
Carbide type area ISO: P
Machining conditions for indexable insert: Good
Carbide type ISO: P15
Carbide type: ACP15T
ISO-Code Rotating: VCMT 160404
Material to be processed: Steel | Cast metal
min./max. ap: 0.5-2.25 mm
f min./max.: 0.07-0.14 mm/U
Materials group: P (primary application) | K (secondary application)
f min.: 0,07 mm/r
max. f: 0,14 mm/r
max. ap: 2,25 mm
min. ap: 0,5 mm
Supply type: Smoothing
Chip breaker code: FP1
Min./max. Vc in steel: 180-400 m/min
Min./max. Vc in cast iron: 140-520 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 12370906

EAN no.: 4050293730616

Product Datasheet
