ATORN indexable insert, negative, DNMG 110404-FP HC7620

ATORN indexable insert, negative, DNMG 110404-FP HC7620

ATORN indexable insert, negative, DNMG 110404-FP HC7620
Item no: 1018566 518

Online price:

Available in 4-6 working days.

Application
For longitudinal turning and copy turning with low cutting depths in moderate cutting conditions

Execution
Sintered cemented carbide indexable insert

Advantage
  • Perfect combination of wear resistance and durability; for high process stability and a broad range of uses
  • Very positive chip breaker for ideal chip breaking in shallow cutting depths


Brand: ATORN
Shape of indexable insert ISO: D
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 11
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 04
Coating: CVD
Carbide type area ISO: P
Machining conditions for indexable insert: Medium
Carbide type ISO: P20
Carbide type: HC7620
ISO-Code Rotating: DNMG 110404
Material to be processed: Steel | Cast metal
min./max. ap: 0.1-1.5 mm
f min./max.: 0.05-0.2 mm/U
Materials group: K (secondary application) | P (primary application)
f min.: 0,05 mm/r
max. f: 0,2 mm/r
max. ap: 1,5 mm
min. ap: 0,1 mm
Supply type: Smoothing - Positive chip breaker for low cutting depths
Chip breaker code: FP
Min./max. Vc in steel: 80-350 m/min
Min./max. Vc in cast iron: 50-290 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 10870570

EAN no.: 4050293351439

Product Datasheet
