ATORN cemented carbide indexable insert CCGT09T301-FU1 HC7820

ATORN cemented carbide indexable insert CCGT09T301-FU1 HC7820

ATORN cemented carbide indexable insert CCGT09T301-FU1 HC7820
Item no: 1018550 205

Online price:

Available in 4-6 working days.

Advantage
  • perfect combination of toughness and resistance to wear, for high degree of process stability and broad range of applications
  • very positive chip breaker, ensures ideal chip breaking with small cutting depths
  • Produces the best surface quality on the component


Brand: ATORN
Shape of indexable insert ISO: C
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: G
Indexable insert type ISO: T
Size of indexable insert ISO: 09
Thickness of indexable insert ISO: T3
Corner radius of indexable insert ISO: 01
Coating: PVD
Carbide type area ISO: M | S | P
Machining conditions for indexable insert: Medium
Carbide type ISO: M10 | M30 | S10 | S30 | P15 | P25
Carbide type: HC7820
ISO-Code Rotating: CCGT 09T301
min./max. ap: 0.1-1.5 mm
f min./max.: 0.02-0.06 mm/U
f min.: 0,02 mm/r
max. f: 0,06 mm/r
max. ap: 1,5 mm
min. ap: 0,1 mm
Supply type: Smoothing - Positive chip breaker for low cutting depths
Chip breaker code: FU1
Min./max. Vc in steel: 30-130 m/min
Min./max. Vc in stainless steel: 60-210 m/min
Min./max. Vc in special alloys: 40-60 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 10875097

EAN no.: 4050293561128

Product Datasheet
