ATORN cemented carbide indexable insert CCGT09T302-FU1 HC7810

ATORN cemented carbide indexable insert CCGT09T302-FU1 HC7810

ATORN cemented carbide indexable insert CCGT09T302-FU1 HC7810
Item no: 1018550 106

Online price:

Available in 4-6 working days.

Application
For longitudinal turning and facing with low cutting depths in favourable cutting conditions

Advantage
  • Very high level of hardness and wear resistance, for high service life requirements with favourable cutting conditions
  • very positive chip breaker, ensures ideal chip breaking with small cutting depths


Brand: ATORN
Shape of indexable insert ISO: C
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: G
Indexable insert type ISO: T
Size of indexable insert ISO: 09
Thickness of indexable insert ISO: T3
Corner radius of indexable insert ISO: 02
Coating: PVD
Carbide type area ISO: M | S | P
Machining conditions for indexable insert: Good
Carbide type ISO: M01 | M20 | S01 | S20 | P05 | P15
Carbide type: HC7810
ISO-Code Rotating: CCGT 09T302
min./max. ap: 0.2-2.0 mm
f min./max.: 0.05-0.12 mm/U
f min.: 0,05 mm/r
max. f: 0,12 mm/r
max. ap: 2,0 mm
min. ap: 0,2 mm
Supply type: Smoothing - Positive chip breaker for low cutting depths
Chip breaker code: FU1
Min./max. Vc in steel: 80-160 m/min
Min./max. Vc in stainless steel: 130-220 m/min
Min./max. Vc in special alloys: 40-70 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 10875115

EAN no.: 4050293561302

Product Datasheet
