Hazardous materials pallet shelf, basic bay, 2 levels w/ collection tray 360 l

Hazardous materials pallet shelf, basic bay, 2 levels w/ collection tray 360 l

Hazardous materials pallet shelf, basic bay, 2 levels w/ collection tray 360 l
Item no: 1085616 102

Online price:

Availability on demand

Application
For storing hazardous materials in barrels on Euro pallets or chemicals pallets.

Execution
  • Pallet shelves:
  • Racks consist of cold-formed profiles screwed to the bracing on site
  • Height-adjustable storage levels in increments of 50 mm
  • Zinc-plated support frame
  • Longitudinal cross beams plastic-coated in RAL 2001 red orange
  • Shelf floor tray:
  • Collecting tray from 3 mm sheet steel
  • Hot-dip galvanised corrosion protection
  • Ground clearance 100 mm

Advantage
  • Pallet shelves with quality mark RAL-RG 614/2 pallet shelves
  • Collection tray according to WHG (German water resources act), test mark according to StawaR (German steel tank guideline)
  • The combination of pallet shelves with quality seals and shelf base trays in accordance with the water resources act gives you a flexible, cost-effective storage system that can be expanded at any time


Brand: LACONT
Height x width x depth: 2700 x 2870 x 1100 mm
Number of levels: 2 PCS
Max. number of 200-litre containers: 12 PCS
Bay load: 7520 kg
Clear width: 2700 mm
Collection volume: 360 l
Depth: 1100 mm
Design: Shelving unit
Height: 2700 mm
Shelf load: 3510 kg
Tray depth: 1300 mm
Tray height: 285 mm
Tray width: 2680 mm
Width: 2870 mm

Manufacturer part no.: R23-3514-D

EAN no.: 4024496127474

Product Datasheet
