Twin leg puller with quick adjustment size 2 clamping width 160mm -depth 150mm

Twin leg puller with quick adjustment size 2 clamping width 160mm -depth 150mm

Twin leg puller with quick adjustment size 2 clamping width 160mm -depth 150mm
Item no: 1078108 103

Online price:

Still in stock: 5

Application
For universal internal and external extraction of gear wheels, ball bearings, bearings etc.

Execution
  • Strong design, special steel
  • Strong spindle and movable spindle tip
  • Spindle head with collar (anti-slip protection)
  • Sliding, permanently parallel legs and large contact surfaces for gentle extraction

Advantage
  • Bar with hexagonal socket for tightening
  • Can be used as either an external or internal extractor
  • Quick release and movement of the hooks without a wrench using the manual setting knurl


Brand: KUKKO
Extractor design: Quickly adjustable hook
Max. external clamping width: 160 mm
Max. internal clamping width: 220 mm
Max. clamping depth: 150 mm
Min./max. external clamping width: 40-160 mm
Min./max. internal clamping width: 100-220 mm
Size: 2

Manufacturer part no.: 20-2+

EAN no.: 4021176644931

Product Datasheet
