Grinding flaps synthetic corundum ISO 3919 30x10 mm shank dia. 6 mm grit 60

Grinding flaps synthetic corundum ISO 3919 30x10 mm shank dia. 6 mm grit 60

Grinding flaps synthetic corundum ISO 3919 30x10 mm shank dia. 6 mm grit 60
Item no: 1043162 110

Online price:

Available for immediate delivery

Application
For fine sanding work in tool and mould making with large curves. For machining smaller, difficult-to-access areas in container and equipment construction. For machining fittings made of non-ferrous base metals and light metals. The flat casting core design allows access to very tight corners and edges on the front side.

Execution
  • DIN 69183 (external dia. 50x15, 60x40, 80x15 mm)
  • The abrasive grain is embedded in the synthetic resin coating of the strong fabric segments
  • Synthetic corundum abrasive grain (AO)
  • Recommended peripheral speed = 15-20 m/s

Advantage
  • Highly flexible and concentric
  • High removal rate due to aggressive sanding belt material
  • Carrier material removes material from the workpiece surface in a uniform manner without leaving residue


Brand: PFERD
Head diameter x head length: 30 x 10 mm
Material of abrasive medium: Aluminium oxide (corundum)
Grain size: 60
Recommended rotation speed: 12000 rpm
Max. rotation speed: 25400 rpm
Binding: Synthetic resin
Material to be processed: Stainless steel | Steel | Grey cast iron | Copper | Brass | Cast steel | Malleable cast iron | Aluminium

Manufacturer part no.: F 3010/6 A 60

EAN no.: 4007220154267

Product Datasheet
