Surface specimen plate face milling, 6 reference specimens N5-N10
Item no: 1033890 203
Online price:
Catalogue price:
You save:
Will be ordered for you
Min. order quantity: 1
Description
Application
For comparative testing of the surface quality by visual and tactile examination (with fingernail), in accordance with standards ISO/R 468, ISO 2632/1 1975 and NF E 05-051.
Execution
For comparative testing of the surface quality
Notes
These specimen plates efficiently illustrate the various surface types that are achieved with machines that are used in industry.
Calibration service is not available for this item.
Technical data
Brand: ---
Machining method: Front milling
Number of comparative patterns: 6 PCS
Min./max. Ra comparison range: 0.40-12.5 µm
ISO surface roughness categories: N5 | N6 | N7 | N8 | N9 | N10
Min. Ra comparison range: 0,40 µm
Max. Ra comparison range: 12,5 µm
Keywords: Oberflächenvergleichsmuster,Oberflächennormal,
