Digitaler Feinzeiger Millimess 2001Wi

Digitaler Feinzeiger Millimess 2001Wi

Digitaler Feinzeiger Millimess 2001Wi
Item no: 1033075 202

Online price:

Available in 6-8 working days.

Application
For measuring lengths. Ideal for comparative measuring instruments and flatness and straightness measurements.

Execution
  • For dynamic and static measurements
  • High-contrast LCD display
  • Operating and display elements can be rotated through 280°
  • Clamping shaft and measuring pin made of hardened stainless steel
  • Linearised inductive absolute measuring system
  • Replaceable measuring force spring
  • Adjustable lower end stop
  • Clear tolerance thresholds in scale display and colour LED signals (red, green, yellow) for classification of measured values
    - with warning threshold input: go/no-go/warning threshold
    - without warning threshold input: go/no-go/rework
  • Features: ON/OFF, mm/inch, RESET, PRESET, ABS (reference to electric zero point), scale increment can be changed, TOL (tolerance and warning threshold input), RANGE (change measuring range and graduation), MAX/MIN memory for finding reversal point, (MAX-MIN) for testing concentricity and evenness, 0 (set analogue scale display to zero), factor (adjustable), reverse counting direction, HOLD (measured value storage), LOCK function (keypad lock), DATA (data transfer), bi-directional data interface (external remote control, query and option to input characteristic values and set specific function locks using MarCom software)

Advantage
  • Hardened glass front with touch control panels
  • Excellent resistance to dust, coolants and lubricants
  • Wear-free touch keys
  • Measuring pin precision ball guide for small reversal range

Delivery
1x dial indicator
1x operating instructions
1x USB data and charging cable
1x plug-in power supply for USB
1x rubber bellows
1x screwdriver for pre-stroke adjustment
1x case


Brand: MAHR
Length measuring range: 1 mm
Type: 2001 Wi
Digit increment: 1 µm
Repeat accuracy: 0,1 µm
Data transmission type: Wireless | Cable
Min./max. measurement force: 0.8-1 N
Digit height: 9 mm
Shank diameter: 8 mm
Shaft length: 28 mm
Error limit: 0,3 µm
Free stroke: 2,5 mm
Dynamic measurement: Yes
Reversal error: 0,3 µm
IP protection class: IP 64
Rotating housing: Yes
Calibration Group: K
Display: Digital
Other standard: Company standard

Manufacturer part no.: 4346801

EAN no.: 4059192064334

Product Datasheet
