ATORN RS-Z basic body centre clamping device, length: max. 128 mm

ATORN RS-Z basic body centre clamping device, length: max. 128 mm

ATORN RS-Z basic body centre clamping device, length: max. 128 mm
Item no: 1027690 652

Online price:

Available in 5-7 working days.

Application
For NC machines and machining centres; increases profitability through fewer tool changes and shorter run times per workpiece; suitable for use on pallet and with robot changing systems.

Execution
  • Robust steel basic body
  • Functional surfaces hardened and polished
  • Centre clamping through left-hand and right-hand spindle threads
  • High repeat accuracy
  • Easy to use
  • Prepared for robot handling thanks to Endutec automation interface

Advantage
  • Stable clamping for high cutting performance
  • Prepared for ATORN ZPS K20 and Lang Quick Point 52; other adaptations for your machine table available on request

Delivery
1x RS-Z centre clamping device basic body with spindle; incl. Endutec interface

Notes
Jaws not included in scope of delivery. These must be procured separately as accessories.

Brand: ATORN
Type: RS-Z 75-125/Endutec
Jaws width: 75 mm
Body width: 75 mm
Body length: 125 mm
Max. length: 128 mm
Tension force: 30 kN
Width across flats: 12 mm

ATORN-No.: 22840062

EAN no.: 4066107028732

Product Datasheet
