High-pressure vice NCA BB 160 mm

High-pressure vice NCA BB 160 mm

High-pressure vice NCA BB 160 mm
Item no: 1027651 103

Online price:

Available in 6-8 working days.

Execution
  • ALLMATIC-compatible jaw interface
  • Small dimensions
  • Optimum ratio between the clamping width and overall length
  • Rigid basic body made from GJS 600
  • Inductively hardened
  • Upper and lower side ground
  • Pairing accuracy 0.02 mm
  • Spindle unit quick-change system

Advantage
  • Fully enclosed spindle
  • Increased functional safety
  • Optimised chip protection
  • Minimal cleaning effort
  • Mechanical power booster

Delivery
Basic body with stepped jaws, 1 hand crank, 4 adjustable clamps

Notes
The overall length remains unchanged even when clamping large workpieces.

Brand: KESEL
Jaws width: 160 mm
Min./max. clamping width: 17-263 mm
Jaws height: 39,2 mm
Height: 164,8 mm
Tension force: 60 kN

Manufacturer part no.: 04.25.265.0000

Product Datasheet
