Fork clamp with lug, slot width 26 mm L=315 mm

Fork clamp with lug, slot width 26 mm L=315 mm

Fork clamp with lug, slot width 26 mm L=315 mm
Item no: 1027106 110

Online price:

Available in 6-8 working days.

Execution
  • With lug
  • Heat-treated steel, painted


Brand: AMF
Slot width (b1): 26 mm
Length (l1): 315 mm
Suitable for screw: M24
Clamping shoe height (a): 40 mm
Clamping shoe width (b2): 70 mm
Width 2 (b3): 43 mm
Length 2 (l2): 83 mm
Length 3 (l3): 56 mm
DIN: 6315

Manufacturer part no.: 70953

EAN no.: 4020772070953

Product Datasheet
