ATORN carbide indexable insert DNMX 150604-FP2 ACP15T

ATORN carbide indexable insert DNMX 150604-FP2 ACP15T

ATORN carbide indexable insert DNMX 150604-FP2 ACP15T
Item no: 1019411 101

Online price:

Available in 6-8 working days.

Notes
Carbide indexable insert DNMX 150604-FP2 ACP15T

Brand: ATORN
Shape of indexable insert ISO: D
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: X
Size of indexable insert ISO: 15
Thickness of indexable insert ISO: 06
Corner radius of indexable insert ISO: 04
Coating: CVD
Carbide type area ISO: P
Machining conditions for indexable insert: Good
Carbide type ISO: P15
Carbide type: ACP15T
ISO-Code Rotating: DNMX 150604
Material to be processed: Steel | Cast metal
min./max. ap: 0.5-4.0 mm
f min./max.: 0.6-1 mm/U
Materials group: P (primary application) | K (secondary application)
f min.: 0,6 mm/r
max. f: 1 mm/r
max. ap: 4,0 mm
min. ap: 0,5 mm
Supply type: Smoothing
Chip breaker code: FP2
Min./max. Vc in steel: 220-400 m/min
Min./max. Vc in cast iron: 140-370 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 12370695

EAN no.: 4050293728507

Product Datasheet
