Brand: ATORN
Shape of indexable insert ISO: C
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 12
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 08
Coating: CVD
Carbide type area ISO: P
Machining conditions for indexable insert: Medium
Carbide type ISO: P25
Carbide type: ACP25T
ISO-Code Rotating: CNMG 120408
Material to be processed: Stainless steel | Cast metal | Steel
min./max. ap: 0.25-2.5 mm
f min./max.: 0.07-0.25 mm/U
Materials group: M (secondary application) | K (secondary application) | P (primary application)
f min.: 0,07 mm/r
max. f: 0,25 mm/r
max. ap: 2,5 mm
min. ap: 0,25 mm
Supply type: Smoothing
Chip breaker code: FP1
Min./max. Vc in steel: 100-240 m/min
Min./max. Vc in cast iron: 120-250 m/min
Min./max. Vc in stainless steel: 70-210 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 12370641

EAN no.: 4050293727968
