Carbide bent lathe chisel DIN 4972/ISO2 right setting angle 45° P10 10 Q

Carbide bent lathe chisel DIN 4972/ISO2 right setting angle 45° P10 10 Q

Carbide bent lathe chisel DIN 4972/ISO2 right setting angle 45° P10 10 Q
Item no: 1018862 209

Online price:

Available in 8-10 working days.

Execution
  • Carbide lathe chisel DIN 4972
  • Right
  • Approach angle 45°
  • With soldered ISO cutting edges in accordance with DIN 4950
  • Cutting edges carbide-tipped.


Brand: LIZZARD
Shank width: 10 mm
Shaft height: 10 mm
Length: 90 mm
Carbide type: P10
Cutting direction: Right-hand cutting
Cutting material: Carbide
DIN: 4972
Shank type: Square
Suitable for material group H: 3
Suitable for material group K: 2
Suitable for material group M: 2
Suitable for material group N: 2
Suitable for material group P: 1

EAN no.: 4030456139203

Product Datasheet
