Cutting insert TDFT4E-0.40L H 20 double-edged w. chip former type -T-

Cutting insert TDFT4E-0.40L H 20 double-edged w. chip former type -T-

Cutting insert TDFT4E-0.40L H 20 double-edged w. chip former type -T-
Item no: 1018758 104

Online price:

Available in 6-8 working days.

Application
For clamp holders art. no. 1018719-1018724 and 1018731-1018736.

Execution
Double-edged, with chip former type T

Notes
(1) = tolerance +/- 0.1 mm

Brand: LIZZARD
Type (Bezeichnung): TDFT 4E-0.40L
Width (W +/- 0.02): 4,0 mm
Height (H): 4,7 mm
Length (L): 20 mm
Radius (R): 0,4 mm
Thickness (a): 3,0 mm
f min./max.: 0.1-0.4 mm/U
Nominal dimension of slot width: 4,0 mm
Carbide type: H 20
Surface: Uncoated
Material to be processed: Cast metal | Non-ferrous metal | Special alloy
Min./max. Vc in cast iron: 70-100 m/min
Min./max. Vc in non-ferrous metals: 90-300 m/min
Min./max. Vc in special alloys: 30-50 m/min

EAN no.: 4024496050307

Product Datasheet
