ATORN indexable insert, negative, DNMG 150612-MM HC7520

ATORN indexable insert, negative, DNMG 150612-MM HC7520

ATORN indexable insert, negative, DNMG 150612-MM HC7520
Item no: 1018566 515

Online price:

Available in 4-6 working days.
Replacement article

Execution
sintered cemented carbide indexable insert

Advantage
  • perfect combination of toughness and resistance to wear, for high degree of process stability and broad range of applications
  • Positive soft-cutting chip geometry with a wide infeed range and stable blades


Brand: ATORN
Shape of indexable insert ISO: D
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 15
Thickness of indexable insert ISO: 06
Corner radius of indexable insert ISO: 12
Coating: CVD
Carbide type area ISO: M
Machining conditions for indexable insert: Medium
Carbide type ISO: M20
Carbide type: HC7520
ISO-Code Rotating: DNMG 150612
Material to be processed: Stainless steel | Special alloy
min./max. ap: 0.8-4 mm
f min./max.: 0.18-0.3 mm/U
Materials group: S (secondary application) | M (primary application)
f min.: 0,18 mm/r
max. f: 0,3 mm/r
max. ap: 4 mm
min. ap: 0,8 mm
Supply type: Medium processing - Universal geometry with wide service range
Chip breaker code: MM
Min./max. Vc in stainless steel: 110-260 m/min
Min./max. Vc in special alloys: 30-60 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 10870446

EAN no.: 4050293352733

Product Datasheet
