ATORN indexable insert CCMT 120404 medium machining MPX HC7520

ATORN indexable insert CCMT 120404 medium machining MPX HC7520

ATORN indexable insert CCMT 120404 medium machining MPX HC7520
Item no: 1018551 542

Online price:

Available in 4-6 working days.
Replacement article

Execution
Sintered cemented carbide indexable insert

Advantage
  • Perfect combination of wear resistance and durability; for high process stability and a broad range of uses
  • Positive soft-cutting chip geometry with a wide infeed range and stable blades


Brand: ATORN
Shape of indexable insert ISO: C
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: T
Size of indexable insert ISO: 12
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 04
Coating: CVD
Carbide type area ISO: M
Machining conditions for indexable insert: Medium
Carbide type ISO: M20
Carbide type: HC7520
ISO-Code Rotating: CCMT 120404
Material to be processed: Stainless steel | Special alloy
min./max. ap: 0.6-5 mm
f min./max.: 0.16-0.4 mm/U
Materials group: M (primary application) | S (secondary application)
f min.: 0,16 mm/r
max. f: 0,4 mm/r
max. ap: 5 mm
min. ap: 0,6 mm
Supply type: Medium processing - Universal geometry with wide service range
Chip breaker code: MPX
Min./max. Vc in stainless steel: 80-240 m/min
Min./max. Vc in special alloys: 30-60 m/min

ATORN-No.: 10875184

EAN no.: 4066107005870

Product Datasheet
