Material to be processed: Cast metal | Steel | Stainless steel | Special alloy | Hardened steel | Non-ferrous metal
Brand: DORMER PRAMET
ISO-Code Rotating: DCGT 11T304
Supply type: Smoothing | Medium finishing
Surface: Coated
Cutting material: SC
Inner circle diameter (IC): 4,4 mm
Knife edge length (L): 11 mm
Mounting bore diameter (D1): 4,4 mm
Corner radius (RE): 0,4 mm
Thickness of indexable insert (S): 3,97 mm
Carbide type: T8430
Chip breaker code: ER-SI
Coating: PVD
Materials group: P (primary application) | M (primary application) | N (secondary application) | K (secondary application) | S (secondary application) | H (secondary application)
Carbide type ISO: N15 | K25 | K40 | S25 | P40 | M20 | H15 | S15 | P20 | M35 | N25 | H20
Machining conditions for indexable insert: Medium
Min./max. Vc in steel: 190-205 m/min
Min./max. Vc in stainless steel: 105-115 m/min
Min./max. Vc in cast iron: 155-170 m/min
Min./max. Vc in special alloys: 40-45 m/min
min./max. ap: 0.8-1.0 mm
f min./max.: 0.12-0.22 mm/U
Number of pieces per packet: 10 PCS

Manufacturer part no.: 7977208

EAN no.: 3603603818194
