ATORN boring bar, positive, with internal cooling A20R SVQBL 11

ATORN boring bar, positive, with internal cooling A20R SVQBL 11

ATORN boring bar, positive, with internal cooling A20R SVQBL 11
Item no: 1018532 111

Online price:

Available in 4-6 working days.

Application
for longitudinal and copy turning with VB indexable insert, 35°

Execution
Precision-made boring bar, steel, with internal cooling, type V, attack angle 107.5°, tip angle 35°, clearance angle 5°

Advantage
  • very slim geometry, optimised for contour turning work
  • positive body geometry ensures low cutting forces


Brand: ATORN
ISO name: A20R SVQB R/L 11
Min. bore diameter (D min.): 25 mm
Shank diameter (d): 20 mm
Clearance length (l2): 20,5 mm
Length (l1): 200 mm
Clamping surface height (h): 18 mm
Suitable for indexable inserts (ISO): VB.. 1103..
Tool design: Left
DIN: 8024

ATORN-No.: 12232491

EAN no.: 4050293562330

Product Datasheet
