ATORN Boring bar A10K SVJCR 07

ATORN Boring bar A10K SVJCR 07

ATORN Boring bar A10K SVJCR 07
Item no: 1018509 101

Online price:

Available in 4-6 working days.

Application
for longitudinal and copy turning with VC indexable insert 35°.

Execution
Precision-manufactured boring bar, steel, with internal cooling, offset, shape C, 52° pitch angle, 35° tip angle, 7° clearance angle

Advantage
  • slender geometry for longitudinal and copy turning
  • positive body geometry ensures low cutting forces


Brand: ATORN
ISO name: A 10K SVJC R/L 07
Min. bore diameter (D min.): 13 mm
Shank diameter (d): 10 mm
Clearance length (l2): 18 mm
Length (l1): 125 mm
Clamping surface height (h): 9 mm
Programming size (f): 1,5 mm
Suitable for indexable inserts (ISO): VC.. 0702..
Tool design: Right
DIN: 8024

ATORN-No.: 11110779

EAN no.: 4050293540109

Product Datasheet
