MINI-MILL insert holder SC shank DIN 6535HA ZH22.1212.42.A.HM

MINI-MILL insert holder SC shank DIN 6535HA ZH22.1212.42.A.HM

MINI-MILL insert holder SC shank DIN 6535HA ZH22.1212.42.A.HM
Item no: 1017580 101

Online price:

Available in 6-8 working days.

Application
For producing grooves, Seeger ring grooves, metric ISO threads, Whitworth pipe threads and full radius grooves and for chamfering and deburring.

Execution
  • SC shank according to DIN 6535 HA
  • With internal coolant supply
  • 3-rib toothing

Notes
For cutting plates, see art. no. 1017582-1017593.

Manufacturer part no.: 11963056
