ATORN SC multi-tooth mill, long diameter 8.0 x 31 x 40 x 75mm T=6 RT65

ATORN SC multi-tooth mill, long diameter 8.0 x 31 x 40 x 75mm T=6 RT65

ATORN SC multi-tooth mill, long diameter 8.0 x 31 x 40 x 75mm T=6 RT65
Item no: 1016825 305

Online price:

Still in stock: 4

Application
Multi-tooth mills for circumferential, ultra-fine finish cutting and semi-rough cutting in materials up to 65 HRC.

Execution
  • Solid carbide ultra-fine grain
  • Centre cutting
  • Edge protection chamfer
  • HA shank in accordance with DIN 6535
  • With clearance
  • Type H
  • Chip angle -26°
  • RockTec 65-coated

Advantage
  • Excellent chip removal and temperature resistance
  • Maximum service life thanks to RockTec 65 coating


Brand: ATORN
Cutting material: SC
Surface: RockTec 65
Type: H
Number of cutting edges (Z): 6 PCS
Twist angle: 50°
Tool holding device: HA parallel shank
Construction length: Long
Cutting edge diameter: 8 mm
Cutting edge length: 31 mm
Clearance length: 40 mm
Length: 75 mm
Edge protection chamfer length: 0,2 mm
Clearance diameter: 7,4 mm
Shank diameter: 8 mm
fz hard 52 HRC: 0,055 mm
Overall stainless steel suitability: 3
fitness not iron total: 3
fitness Titan/Nickel/Super total: 3

ATORN-No.: 11860694

EAN no.: 4050293199642

Product Datasheet
Versions
loading
Keywords:

[Text nicht gefunden]

  • ATORN countersink, 90°, HSS, T=3, 40.0 x 140 mm, DIN 335 shape D MK 3
  •
    ATORN screw tap HSSE C 376 45° M16 2 mm ISO2 S 2.5xD CNC N
  •
    ATORN screw tap HSSE C 376 15° M16 2 mm ISO2 S 2.5xD CNC P
    44,98 €
  • ATORN SC multi-tooth mill, long diameter 4.0 x 19 x 32 x 75mm T=6 RT52
  •
    ATORN SC radius cutter long diameter 6.0 x 10 x 20 x 50 mm T=2 RT52
  •
    ATORN SC radius cutter long diameter 12.0 x 16 x 38 x 75 mm T=2 RT52
  •
    ATORN SC radius cutter diameter 16.0 x 32 x 46 x 90 mm T=4 RT65
    207,00 €
  • Precision collet chuck GERC 20-B/428 E hole 9.0 mm
  •
    Precision collet chuck GERC 40-B/472 E hole 20.0 mm
  •
    Ersatzkopf Nylon Gr. 6 50 mm
  •
    ATORN spare impact insert 25 mm made from cellulose acetate, blue
