ATORN SC multi-tooth mill ER TiAlSiN 16x36x92 mm edge radius 0.5 mm

ATORN SC multi-tooth mill ER TiAlSiN 16x36x92 mm edge radius 0.5 mm

ATORN SC multi-tooth mill ER TiAlSiN 16x36x92 mm edge radius 0.5 mm
Item no: 1016788 132

Online price:

Still in stock: 3

Application
Torus multi-tooth mills in standard design for machining materials up to 65 HRC, e.g. in die and mould making.

Execution
  • Cutting material, Ultra Micro fine grain
  • cutting edge finish
  • HA shaft in line with DIN 6535
  • with clearance
  • type H
  • With RockTec PRO coating
  • Radius tolerance = +/- 0.005 mm

Advantage
  • optimum chip removal and temperature resistance
  • Optimised geometry for machining hard materials
  • maximum service life thanks to RockTec PRO coating


Brand: ATORN
Cutting material: SC
Surface: RockTec PRO
Type: H
Number of cutting edges (Z): 8 PCS
Twist angle: 45°
Tool holding device: HA parallel shank
Construction length: Normal
Cutting edge diameter: 16 mm
Cutting edge length: 36 mm
Length: 92 mm
Shank diameter: 16 mm
Edge radius: 0,5 mm
fz hard 65 HRC: 0,088 mm

ATORN-No.: 11264027

EAN no.: 4050293652567

Product Datasheet Datasheet cutting values
