ATORN SC torus mill cttr long TiAlSiN 5x5.5x80 mm clearance 4.7x40 mm R 0.3 mm

Versions

Item no: 1016786 124

Online price:

Catalogue price: You save:

Still in stock: 3

Min. order quantity: 1

Application
Torus milling cutter in long design for machining materials up to 65 HRC, e.g. in die and mould making.

Execution

Cutting material, Ultra Micro fine grain
cutting edge finish
HA shaft in line with DIN 6535
Clearance
type H
With RockTec PRO coating
Radius tolerance = +/- 0.005 mm

Advantage

optimum chip removal and temperature resistance
Optimised geometry for machining hard materials
maximum service life thanks to RockTec PRO coating

Brand: ATORN
Cutting material: SC
Surface: RockTec PRO
Type: H
Number of cutting edges (Z): 4 PCS
Twist angle: 30°
Tool holding device: HA parallel shank
Construction length: Extra long
Cutting edge diameter: 5 mm
Cutting edge length: 5,5 mm
Clearance length: 40 mm
Length: 80 mm
Clearance diameter: 4,7 mm
Shank diameter: 6 mm
Edge radius: 0,3 mm
fz hard 65 HRC: 0,04 mm

ATORN-No.: 11264296

EAN no.: 4050293655254

Product Datasheet Datasheet cutting values
