SC angle cutter 60° shape D 9 cttng edges DIN 6535 HB Alcrona L=71 mm di 32 mm

SC angle cutter 60° shape D 9 cttng edges DIN 6535 HB Alcrona L=71 mm di 32 mm

SC angle cutter 60° shape D 9 cttng edges DIN 6535 HB Alcrona L=71 mm di 32 mm
Item no: 1016662 406

Online price:

Available in 6-8 working days.

Application
For cutting angle grooves (slide guideways etc.)

Execution
  • Shape D
  • Cutting edge tapering in the direction of the end face
  • Only cuts on periphery
  • Straight shank with driving surface in accordance with DIN 1835 B
  • Right-cutting

Notes
Drive up to full engagement fz with 50 %.

Brand: LIZZARD
Material to be processed: Steel | Stainless steel | Cast metal
Chamfer angle: 60 Degree
Cutting edge diameter: 32 mm
Width of cutting edge: 12,5 mm
Length: 71 mm
Shank diameter: 16 mm
Number of cutting edges (Z): 9 PCS
DIN: 1833
Coolant supply: External
Form: D
Cutting angle: 60
