VHM-HPC Torusfräser INOX Gr.M Alcrona Pro HB-Schaft Z4 Ø 6 ER2,0

VHM-HPC Torusfräser INOX Gr.M Alcrona Pro HB-Schaft Z4 Ø 6 ER2,0

VHM-HPC Torusfräser INOX Gr.M Alcrona Pro HB-Schaft Z4 Ø 6 ER2,0
Item no: 1016596 118

Online price:

Available for immediate delivery

Application
For universal roughing and finishing in stainless steels, optimum machining performance even at high cutting speeds. Also suitable for steels up to 1,100 N/mm2.

Execution
  • Unequal cutting edge pitch
  • With corner radius
  • With clearance

Advantage
  • Extremely smooth running
  • Defined edge rounding for maximum service life
  • Minimal heat generation
  • Optimised geometry
  • Reinforced core diameter


Brand: LIZZARD
Material to be processed: Stainless steel | Universal use
Cutting edge diameter: 6 mm
Corner radius: 2,0 mm
Cutting edge length: 13 mm
Clearance length: 19 mm
Length: 57 mm
Clearance diameter: 5,8 mm
Shank diameter: 6 mm
Number of cutting edges (Z): 4 PCS
Twist angle: 35-38°
Type: UNI
Construction length: Normal
Design of cutting edges: Smoothing
Cutting direction: Right-hand cutting
fz stainless steel: 0,019 mm

Versions
loading
Keywords:

You might also be interested in this

  • VHM-HPC Torusfräser INOX Gr.M Alcrona Pro HB-Schaft Z4 Ø 8 ER0,1
  •
    VHM-HPC Torusfräser INOX Gr.M Alcrona Pro HB-Schaft Z4 Ø 4 ER0,5
    30,80 €
  • VHM-HPC Torusfräser INOX Gr.M Alcrona Pro HB-Schaft Z4 Ø 6 ER0,3
    30,80 €
  • ATORN SC torus milling cutter, extra-long, Ø 6.0x10x60x100mm r1.0 T=4 RT65
  •
    ATORN screw tap HSSE V3 vaporised B thread 7/8 3xD CNC UNI
  •
    VHM-HPC Torusfräser INOX Gr.M Alcrona Pro HB-Schaft Z4 Ø 8 ER1,5
  •
    LIZZARD Spannzange ER 11 HP Ø 6,0 Gummi abgedichtet Rundlauf 0,005 mm
  •
    Datenkabel Modell D - DIGIMATIC 1 Meter
  •
