SC HPC torus milling cutter G2 TiAlN 35/38° normal HB shank T=4 dia. 20 R2.0

SC HPC torus milling cutter G2 TiAlN 35/38° normal HB shank T=4 dia. 20 R2.0

SC HPC torus milling cutter G2 TiAlN 35/38° normal HB shank T=4 dia. 20 R2.0
Item no: 1016540 133

Online price:

Still in stock: 8

Application
for universal use up to 1,300 N/mm² and up to HRC 52.

Execution
  • Normal, type H
  • Centre cutting
  • Optimised chip chamber
  • Up to 80% longer service life
  • Up to 60% more feed
  • Roughing and finishing with just one tool

Advantage
  • Uneven twist angle produces smooth, vibration-free running and good surface quality
  • High cutting performance


Brand: LIZZARD
Material to be processed: Universal use
Cutting edge diameter: 20 mm
Corner radius: 2,0 mm
Cutting edge length: 38 mm
Length: 104 mm
Shank diameter: 20 mm
Number of cutting edges (Z): 4 PCS
Twist angle: 35-38°
Type: H
Construction length: Normal
Design of cutting edges: Smoothing
Cutting direction: Right-hand cutting
fz steel 1000: 0,105 mm
