Schaftfräser zyl./1835 B DIN 844 B Typ N lang 4 Schn. Z-Schnitt HSS-E 20 mm

Schaftfräser zyl./1835 B DIN 844 B Typ N lang 4 Schn. Z-Schnitt HSS-E 20 mm

Schaftfräser zyl./1835 B DIN 844 B Typ N lang 4 Schn. Z-Schnitt HSS-E 20 mm
Item no: 1016128 223

Online price:

Still in stock: 6

Execution
  • Lang
  • Rechtsschneidend
  • Rechtsdrall 30°
  • 4-6 Schneiden
  • Zentrumschnitt
  • Zylinderschaft mit Mitnahmefläche nach DIN 1835B


Brand: LIZZARD
Material to be processed: Universal use
Cutting edge diameter: 20 mm
Cutting edge length: 75 mm
Length: 141 mm
Shank diameter: 20 mm
Clearance diameter: 19,0 mm
Number of cutting edges (Z): 4 PCS
Twist angle: 30°
Type: N
Construction length: Long
Coolant supply: External
Design of cutting edges: Smoothing
Cutting direction: Right-hand cutting
Tolerance of cutting edge diameter: h10
Tolerance of shank diameter: h6

Versions
