ATORN machine tap M1.7 HSSE vaporised for through hole

ATORN machine tap M1.7 HSSE vaporised for through hole

ATORN machine tap M1.7 HSSE vaporised for through hole
Item no: 1014346 096

Online price:

Available in 6-8 working days.

Application
For producing metric threads on CNC machines or conventional machines in through holes in the steel, stainless steel, non-ferrous metals and cast iron material groups up to a strength of 1000 N/mm².

Execution
Structural dimensions in accordance with: DIN 371 = reinforced shank (up to M10), DIN 376 = over-long shank (from M12)

Advantage
  • Universal use for maximum flexibility in use
  • Innovative cutter geometry ensures high process reliability even in difficult machining conditions


Brand: ATORN
Material to be processed: Universal use
Thread type: Metric thread
Thread type x nominal diameter: M1.7
Tolerance of screw taps (Tol.): ISO 2 (6H)
Hole type: Clearance hole ≤ 3xD
Lead angle shape: B
Length: 40 mm
Cutting material: HSSE
Surface: Vaporised
Pitch: 0,35 mm
Twist angle: 0°
DIN: 371
Shank diameter: 2,5 mm
Application type/machine type: CNC | Conventional
Core hole diameter: 1,35 mm
Type: UNI 40 Control
Coolant supply: External
Shank square: 2,1 mm
Cutting speed (steel 1000) suitability (ISO P 1000 N/mm²): 1
Cutting speed (steel 1300) suitability (ISO P 1300 N/mm²): 2
Overall stainless steel suitability (ISO M): 1
fitness not iron total (ISO N): 2
fitness Titan/Nickel/Super total (ISO S): 3
Cutting speed (cast) suitability (ISO K): 1
Cutting speed (hard 55) suitability (ISO H 55HRC): 3
Cutting speed (hard 65) suitability (ISO H 65HRC): 3

ATORN-No.: 11290905

EAN no.: 4050293415384

Product Datasheet Datasheet cutting values
Versions
loading
Keywords:

[Text nicht gefunden]

  • ATORN screw tap HSSE TiCN B 371 0° M10 1.5 mm ISO2 D 3xD CNC P
  •
    ATORN machine tap M 27 HSSE vaporised for through hole
  •
    Machine tap G DIN 5156 15° shape C 2.5xD HSS-E 1.1/2 inch
  •
    Mini cutter str./1835 B short, 3 cutting edges centre cutting HSS-E/TiAlN 4.8 mm
  •
    ATORN replacement clamp RS-Z 125-180
  •
    Digital dial gauge measuring range 25 mm reading 0.01 mm IP 42
  •
    Light meter TESTO 540 units lux, foot candle
  •
    ATORN ratchet combination wrench, size 9 mm, with two-sided ratchet function
  •
    VDE-Elektriker-Kreuzschlitz-Schraubendreher SoftFinish-Griff PZ 1
    8,06 €
  • Nylon fish tape, extremely robust with steel end pieces length 10 m
  •
