Hand tap DIN 352 no. 1 taper tap HSS polished M3

Hand tap DIN 352 no. 1 taper tap HSS polished M3

Hand tap DIN 352 no. 1 taper tap HSS polished M3
Item no: 1014026 110

Online price:

Available for immediate delivery

Application
For production of standard ISO DIN 13 metric threads. For unalloyed and low-alloy steels up to 800 N/mm² strength.

Execution
  • Taper tap with chamfer shape A with one ring
  • Right-cutting
  • Straight-grooved
  • HSS, ground


Brand: LIZZARD
Thread type x nominal diameter: M3
Pitch: 0,5 mm
Core hole diameter: 2,50 mm
Length: 40 mm
Shank diameter: 3,5 mm
Shank square: 2,7 mm
Colour ring system: Steels
Design: Taper tap
Shank style: Cylindrical with square drive
Thread type: Metric thread
Lead angle shape: A
DIN: 352
Cutting material: HSS
Cutting direction: Right-hand cutting
Hole type: Clearance/blind hole ≤ 2.5xD
Surface: Uncoated
Tolerance of screw taps: 6H
Nominal diameter: 3 mm
Twist angle: 0°

EAN no.: 4024496017454
