Step. drill bit str. with 2 cutting edges HSS for drilling dia. 7.0–39.6 mm

Step. drill bit str. with 2 cutting edges HSS for drilling dia. 7.0–39.6 mm

1010924138 Step. drill bit str. with 2 cutting edges HSS for drilling dia. 7.0–39.6 mm
Item no: 1010924 138

Online price:

Still in stock: 8

Application
For drilling in sheet metal made of almost any metal alloy of 0.4 to 3 mm thickness.

Execution
Diameter tolerance +/- 0.13 mm

Notes
The tool operates without chattering or jamming, even when the cut is interrupted. Holes are deburred precisely and cleanly on the entry side. Turning the workpiece means the exit point is also deburred quickly.
Coolant stick, see art. no. 1010937 101.

Brand: LIZZARD
Max. material thickness: 4 mm
Min./max. cutting edge diameter: 7-39.6 mm
Type: 5

EAN no.: 4024496008353

Product Datasheet
