Twist drill bit HSS-E-Co8 AG-coated DIN 338 118° tip angle 5xD dia. 1.9 mm

Twist drill bit HSS-E-Co8 AG-coated DIN 338 118° tip angle 5xD dia. 1.9 mm

Twist drill bit HSS-E-Co8 AG-coated DIN 338 118° tip angle 5xD dia. 1.9 mm
Video
Item no: 1010423 019

Online price:

Available in 6-8 working days.

Application
For steel up to 1200 N/mm² and cast iron. Drilling in increments, without removing chips.

Execution
  • Straight shank
  • Right-cutting
  • Special flute geometry
  • Tip angle 118°
  • Helix angle 34°
  • HSSE Co8, ground
  • Ag(AlCr) coating

Notes
Note the respective length/diameter ratio of the bore diameter and the flute length. Use only high-precision tool chucks!

Brand: NACHI
Material to be processed: Steel | Cast metal
Cutting edge diameter: 1,9 mm
Length: 46 mm
Chip flute length: 22 mm
Max. drilling depth (D): 5xD
Angle of the tip: 118 Degree
Cutting material: HSSE Co8
Surface: AlCrN
Tool holding device: Cylinder shank
Type: AGPSD
DIN: 338
Coolant supply: External
Cutting direction: Right-hand cutting
Number of cutting edges: 2 PCS
f steel 1000: 0,05 mm/r
Min. f in steel: 0,036 mm/r
Max. f in steel: 0,060 mm/r
Min. f in cast iron: 0,080 mm/r
Max. f in cast iron: 0,080 mm/r

Manufacturer part no.: L6536 1,9

Product Datasheet Datasheet cutting values
