Long twist drill bit DIN 340 type FS HSS ground 5.8 mm

Long twist drill bit DIN 340 type FS HSS ground 5.8 mm

Long twist drill bit DIN 340 type FS HSS ground 5.8 mm
Item no: 1010407 344

Online price:

Available in 11-13 working days.

Application
For normally machinable materials up to approx. 900 N/mm².

Execution
  • With straight shank
  • Right-cutting
  • Cone polished section
  • Tip angle 130°
  • With thinned chisel edge in accordance with DIN 1412 shape A
  • Wide chip grooves with highly rounded back edges
  • HSS, ground

Notes
For drilling deep holes (5–10 x D) without chip removal.

Brand: LIZZARD
Material to be processed: Steel
Cutting edge diameter: 5,8 mm
Length: 139 mm
Chip flute length: 91 mm
Angle of the tip: 130 Degree
Cutting material: HSS
Surface: Vaporised
Tool holding device: Cylinder shank
Type: FS
DIN: 340
Coolant supply: External
Cutting direction: Right-hand cutting
Number of cutting edges: 2 PCS
f aluminium: 0,07 mm/r
Min. f in steel: 0,06 mm/r
Max. f in steel: 0,14 mm/r
Min. f in cast iron: 0,08 mm/r
Max. f in cast iron: 0,08 mm/r

Versions
loading
Keywords:

[Text nicht gefunden]

  • Twist drill bit HSS-PM SG-coated 135° tip angle 5xD dia. 7.6 mm
  •
    Long twist drill bit DIN 340 type FS HSS ground 2.7 mm
  •
    Long twist drill bit DIN 340 type FS HSS ground 5.0 mm
    8,53 €
  • Long twist drill bit DIN 340 type FS HSS ground 5.2 mm
  •
    Long twist drill bit DIN 340 type FS HSS ground 6.8 mm
    17,70 €
  • Through hole screw tap MF DIN 374 shape B 2.5xD HSS-E MF6x0.75
  •
    Thread milling cutter single-edge cutter sub-profile 60° 0.5-0.8 mm 2.45 mm
  •
    TC bur spherical (KUD), shank dia. 6 mm, serration 4, head dia.xlength 12x10 mm
    59,05 €
  • 3/8 inch bi-hexagon socket long CV steel AF 17 mm
    14,94 €
  • 3/8 inch jointed hexagon socket CV steel AF 14 mm
  •
    Syphon pliers, 4-way adjustable for SW up to 80 mm length 235 mm CV steel
    28,38 €
  • Spray bottle holder 1x width x dia. 76 x 52 mm anthracite
