Kurzer Spiralbohrer DIN 338 Typ N HSS geschliffen 11,0 mm

Kurzer Spiralbohrer DIN 338 Typ N HSS geschliffen 11,0 mm

Kurzer Spiralbohrer DIN 338 Typ N HSS geschliffen 11,0 mm
Item no: 1010003 501

Online price:

Available for immediate delivery

Application
Für Stähle bis 900 N/mm².

Execution
  • Zylinderschaft
  • Rechtsschneidend
  • Kegelmantel-Anschliff
  • Vaporisiert

Delivery
Packungseinheit: Bohrer-Ø 1,0-7,5 mm = 10 Stück (Preis pro Stück)
Packungseinheit: Bohrer-Ø 7,6-10,5 mm = 5 Stück (Preis pro Stück)


Brand: LIZZARD
Material to be processed: Steel
Cutting edge diameter: 11,0 mm
Length: 142 mm
Chip flute length: 94 mm
Max. drilling depth (D): 5xD
Angle of the tip: 118 Degree
Cutting material: HSS
Surface: Vaporised
Tool holding device: Cylinder shank
Type: N
DIN: 338
Coolant supply: External
Cutting direction: Right-hand cutting
Number of cutting edges: 2 PCS
f steel 700: 0,25 mm/r

Versions
loading
Keywords:

[Text nicht gefunden]

  • ATORN flap wheel diameter 6 mm 30 x 15 mm G40
  •
    ATORN indexable insert CBN CNGA 120404 ABC X15-B-2
  •
    ATORN high-perf. drill, SC TiAlN, HPC 30xD 10.0 mm x 10 mm x 380 mm HA internal
  •
    LIZZARD WENDEPLATTEN APMT 1003 PDR-M HPU35-M
  •
    Kurzer Spiralbohrer DIN 338 Typ N HSS geschliffen 10,5 mm
  •
    Maschinen-Gewindebohrer Rekord 2B-Z-PM-GLT-1 M14-6HX
  •
    ATORN flap wheel diameter 3 mm 30 x 10 mm G80
  •
    ATORN metal circ saw blade, SC, coarse tooth, 30 mm x 5 mm x 8 mm, B T=24
  •
    ATORN high-perf. drill, SC TiAlN, HPC 20xD 10.0 mm x 10 mm x 290 mm HA internal
  •
    Kurzer Spiralbohrer DIN 338 Typ N HSS geschliffen 0,3 mm
  •
    Kranwaage Typ HFA 600K-1
  •
