Micrometer for thread measurement 50-75 mm pitch 5.5-7 mm

Micrometer for thread measurement 50-75 mm pitch 5.5-7 mm

Micrometer for thread measurement 50-75 mm pitch 5.5-7 mm
Item no: 1001354 945

Online price:

Available in 11-13 working days.

Application
For measuring the flange diameter of threads

Execution
  • Micrometer with ratchet tool for reproducible measurements
  • Semi-gloss chrome-plated scale drum and sleeve, dia. 18 mm

Delivery
Includes box, setting standard 60° (from 25 mm), adjustment wrench


Brand: MITUTOYO
Min./max. length measuring range: 50-75 mm
Digit increment: 0,01 mm
Min./max. pitch: 5.5-7 mm
Min./max. number of thread starts per inch: 3.5-5
Measuring spindle increments: 0,5 mm
Error limit: 0,003 mm
Bracket depth: 49 mm
Spindle clamping: Yes
Angle of the tip: 60
Number of setting dimensions: 1 PCS
Calibration Group: F

Manufacturer part no.: 125-115
