Measuring and clamping vee blocks 80 mm w switch magnet, wooden case

1036341311 Measuring and clamping vee blocks 80 mm w switch magnet, wooden case
Item no: 1036341311

Online price:

Still in stock: 4
Buy now

Application
For checking, marking off and aligning cylindrical parts.

Execution
  • Level and parallel and rectangular machined
  • Magnetic force can be turned on/off
  • The side opposite the switch is designed as a magnetic surface
  • Ungehärtete Ausführung strukturlackiert lichtgrau RAL 7035

Delivery
In a wooden case


Brand: ATORN
Design: Standard
Length x width x height: 80 x 67 x 96 mm
Flatness tolerance: 0,004 mm
Min./max. workpiece diameter: 6-66 mm
Angle: 90 Degree

ATORN-No.: 30380112

EAN no.: 4050293337716

Product Datasheet
